High Quality CNC Machining Center HY-850C HY-850C manufacturer from China HUAN YU CNC MACHINE CO.,LTD

Payment Terms:	T/T,L/C
Place of Origin:	Guangdong, China (Mainland)

Product Detail

Model No.: HY-850C

Production Capacity: 100

Delivery Date: in 15 working days after pa...

Means of Transport: Ocean,Land

Packing: Wooden Packing

Factory direct sales,good quality, best price, first-level after-sale service, good reputation.

CNC Machine Center 850C Parameter:

Machine Features:

The machine has perfect design and stable structure.

The machine castings are made by high-level resin sand, which have quenched twice and have good rigidity and they can not be deformed

With three linkage feed device.

The self-lubricated system can protect the machine's lubrication.

With voltage stabilizer to make sure the stable power supply and the normal machine work

Model	HY-850C
Work table Dimension	1000*530mm
Travel of X Axis	800mm
Travel of Y Axis	500mm
Travel of Z Axis	650mm
Maximum Load of Work Table	600kg
T-slot Type	18mm5150mm
Spindle RPM	60-8000rpm
Tool Holder Type	BT40
Drive Motor Power	10HP(7.5KW)
Distance From Spindle nose to Table	120-650mm
Optional System	MITSUBISHI,FANUC
Maximum Feed of X,Y,Z Axis	18000mm/min
Positioning Accuracy of X,Y,Z Axis	0.005mm/300mm
Machine Weight	5500kg
Machine Dimension(LWH)	270024002600mm
